Elite Target Systems™
Proficiency Through Training & Practice
System Specifications
Structure & Drivetrain Portable Targets• Primary Materials: 6061T6 Aircraft-grade Aluminum and 18/8 Stainless Steel• Overall Dimensions (collapsed): 60” long x 5” deep x 9” high• Overall Dimensions (deployed): 66” wide x 40” deep x 70" high• Wind Stability: 30 mph with two 24” x 36” targets mounted vertically at 70” high• Weight: 26 pounds including battery Portable Targets• Battery: 12VDC/7Ah (A new battery with a full charge will provide 10,000+ presentations)• Motor: Industrial grade with ball bearings in motor and gearbox • Flexilock Drive Rod System™
Command Module Portable Targets• Overall Dimensions: 7” long x 3.5” wide x 2” high• LCD Screen: 3.75” long x .75” high viewable area (2 lines x 16 characters each)• User Adjustable Modes: Seven• Standard wireless remote control range up to 1000' under ideal conditions• Optional wireless range to 2600'(1/2 mile) or more with Extended Range Antenna and cable• Routines may be switched remotely from the firing line
• The TAC II meets all applicable FCC requirements
Built-in Modes and Timed Intervals• Routines Mode: Create a Routine, or select from 15 user-definable Routines that are saved even when the Command Module is turned off• Operating Mode: Manual, Auto-Immediate, Auto-Delay Random (3-10) seconds, AutoDelay 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 seconds• Display Period: Random (1-3 seconds), .5, 1, 2, 3, 4, 5, 6, 8, 10, 15, 20, 30 seconds (Chngd on 050118)• Redisplay Mode: Random, Always On, Always Off, Repeat Display Period• Pause Before Redisplay: Random (1-10 seconds), or 1, 2, 3, 4, 5, 6, 7, 8, 9, or 10 seconds• Redisplay Period: Random (1-3 seconds), .5, 1, 2, 3, 4, 5, 6, 8, 10, 15, 20, 30 seconds (Chngd on 050118)• Save as a Routine: 15 Routines may be saved internally
Command Module Portable Targets• Overall Dimensions: 7” long x 3.5” wide x 2” high• LCD Screen: 3.75” long x .75” high viewable area (2 lines x 16 characters each)• User Adjustable Modes: Seven• Standard wireless remote control range up to 1000' under ideal conditions• Optional wireless range to 2600'(1/2 mile) or more with Extended Range Antenna and cable• Routines may be switched remotely from the firing line
• The TAC II meets all applicable FCC requirements
Built-in Modes and Timed Intervals• Routines Mode: Create a Routine, or select from 15 user-definable Routines that are saved even when the Command Module is turned off• Operating Mode: Manual, Auto-Immediate, Auto-Delay Random (3-10) seconds, AutoDelay 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 seconds• Display Period: Random (1-3 seconds), .5, 1, 2, 3, 4, 5, 6, 8, 10, 15, 20, 30 seconds (Chngd on 050118)• Redisplay Mode: Random, Always On, Always Off, Repeat Display Period• Pause Before Redisplay: Random (1-10 seconds), or 1, 2, 3, 4, 5, 6, 7, 8, 9, or 10 seconds• Redisplay Period: Random (1-3 seconds), .5, 1, 2, 3, 4, 5, 6, 8, 10, 15, 20, 30 seconds (Chngd on 050118)• Save as a Routine: 15 Routines may be saved internally
For an additional charge we can supply timing intervals that meet your, or your state's, specific requirements
Minimum Target Width (with wooden supports located hidden behind targets): 17.75” (IPSC=18”)Typical Silhouette Target Width: 24"Typical Silhouette Target Height: 36"Temperature: Range of Operation: 0° to 140°F
Detail Photographs
Click on pictures to get more information
TAC II Command Module
Motor Drive
Support Tube Quick-pins
Carrying Case (Available From Others)
Carrying Case (Available From Others)
TAC II Fully Collapsed
